ATI 6006 6-Channel Amplifier
ATI 6006 6-Channel Amplifier
Couldn't load pickup availability
This item does not include a manufacturer's warranty.
ATI Amplifier Technologies - AT6000 Series - Class AB Power Amplifier - Trade-in (Like New)
If you're looking for a multi-channel stereo amplifier that delivers outstanding performance and reliability, the ATI AT6000 Series Class AB Amplifier is worth considering. This amplifier features advanced circuitry and robust construction, making it an ideal choice for audiophiles and home theater enthusiasts alike. The AT6000 Series is part of ATI's Signature Series 6000, which represents the pinnacle of the company's amplifier design.
The ATI AT6000 Series is a versatile amplifier that can power a wide range of speakers. It is available in 2, 3, 4, 5, 6, and 7 channel configurations, with each channel rated at 300 watts into 8 ohms. The amplifier uses discrete bipolar output devices and a large toroidal power transformer to deliver clean, dynamic sound with low distortion. It also features a high-current power supply that can handle the demands of complex musical passages and explosive movie soundtracks.
The ATI AT6000 Series is designed for ease of use, with features like a front panel display that shows power output, channel status, and temperature, and a menu system that allows you to configure the amplifier for your specific needs. It also includes protection circuits that guard against short circuits, DC faults, overheating, and overloading. With its excellent performance, reliability, and ease of use, the ATI AT6000 Series Class AB Amplifier is a top choice for anyone who wants to take their home theater or audio system to the next level.
FEATURES:
- High-current output
- Advanced protection circuitry
- Toroidal transformers
- Gold-plated connectors
- Input level controls
- 12V trigger input and output
- Rack-mountable design
SPECIFICATIONS:
| Numbers of Channels: | 2 - 7 |
| FTC Full Bandwidth Power Output (8 Ohms): | 300W RMS |
| FTC Full Bandwidth Power Output (4 Ohms): | 450W RMS |
| Input Sensitivity (8 Ohms): | 2.0V |
| Frequency Response (±0.ldB): | 20Hz - 20kH |
| Phase Response (+5 to -15°): | 20Hz - 20kHz @ 1W |
| SNR: | >125dB |
| THD + Noise (20Hz - 20kHz): | <0.03% |
| Intermodulation Distortion: | <0.03% |
| Recommended Load Impedance: | 4 Ohms - 16 Ohms |
| Power Bandwidth FTC (5Hz - 100kHz): | +0,-3dB |
| Damping Factor: | >400 |
| Crosstalk (20Hz - 20kHz): | >–80dB |
| RCA Input Gain (±0.2dB): | 28dB |
| XLR Input Gain (±0.2dB): | 28dB |
| Slew Rate: | >60V/µS |
| Input Impedance: | 28k Ohms |
| Output DC Offset: | <±1mV |
| Chassis Dimensions: | H 9.5" x W 17.3" x D 19.8" (H 241mm x W 440mm x D 502mm) |
| Weight: | 140 lbs (63.5kg) |
DOWNLOADS:
ATI Amplifier Technologies - AT 6000 - Owner's Manual (PDF)
WARNING
Each power cord for the AT6005, AT6006, and AT6007 must be plugged into separate 15A circuits (120VAC) or 8A circuits (230VAC). Separate circuits are connected to different circuit breakers at the service entrance (breaker box) of the building.
