Size & weight
- Net weight15.55kg (34.3 lb)
-
DimensionsHeight: 440mm (17.3 in)
Width: 240mm (9.4 in)
Depth: 373mm (14.7 in)
Technical Details
-
Technical featuresDiamond tweeter
Solid body Tweeter-on-Top
Continuum™ cone bass/mid
Matrix™
Anti-Resonance plug
Flowport
- Description2-way vented-box system
-
Drive units1x ø25mm (1in) Diamond dome high-frequency
1x ø165mm (6.5in) Continuum cone bass midrange - Frequency range34Hz to 35kHz
- Frequency response42Hz to 28kHz (+/-3dB from reference axis)
- Sensitivity88dB (on axis at 2.83Vrms at 1m)
-
Harmonic distortion2nd and 3rd harmonics (90dB, 1m on axis)
<1% 90Hz – 20kHz
<0.3% 120Hz – 20kHz
- Nominal impedance8Ω (minimum 4.6Ω)
- Recommended amplifier power50W – 120W into 8Ω on unclipped programme
- Max recommended cable impedance0.1Ω
Finishes
-
Cabinet finishesGloss Black
White
Satin Rosenut
Satin Walnut -
Grille finishesBlack
Grey
Black
Grey
